10 wheeler Sinotruk Howo 30 ton mining haul truck Description:
- 10 wheeler Sinotruk Howo 30 ton mining haul truck also called dump truck, dump tipper, side-turn tipper, dump truck tipping, dumper, tip truck, tipper lorry.
- is a truck used for transporting loose material, such as sand, gravel, coal, dirt, etc.
- ISUZU dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front.
- Or hinged at side with hydraulic pistons to lift the side.
Advantage:
- Sinotruk HOWO chassis, perfect performance
- Sino engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Pay loading from 2ton to 100 tons.
- Easy operation and easy maintenance.
- Virious types of tipper body are available.
- High strength box body
- Excellent Chinese brand hydraulic piston
- Strong, durable, perfect performance
Specification:
| Truck Model | ZZ3257N3647A | ||
| Truck Brand | 10 wheeler Sinotruk Howo 30 ton mining haul truck Mauritius | ||
| Dimension(Lx W xH) | 8214x2496x3386 | ||
| Cargo body size (L*W*H, mm) | 5400x2300x1400 | ||
| Cargo body thickness(mm) | bottom:8mm, side:6mm, | ||
| Lift type of Carriage | Ventral lifting | ||
| Wheel base (mm) | 3625+1350 | ||
| Curb weight(kg) | 12290 | ||
| Loading Weight(kg) | 30000 | ||
| Fuel tanker capacity | 300L with locking fuel cap | ||
| Fuel consumption(L/100km) | 32 | ||
| Clutch | Single-plate dry clutch Φ420mm | ||
| Engine Model | Model | WD615.47, | |
| Horse Power, max(kw/rpm) | 371HP,247/2200 | ||
| Emission Standard | EURO II | ||
| Transmission | Model | HW 19710,10 forwards and 2 reverse | |
| Steering system | Model | ZF8118, | |
| Front axle | HF9 , | ||
| Rear axle | HC16, | ||
| Color | Optional | ||
| Tire | 12.00R20 11 pieces | ||
| Cab | HW76 cab, (one sleeper,with air-condition | ||
Dumper truck Structure:
Tipper truck parts tools and instructions:
Factory Advantage:
- 19 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Documents:
- Serving more than 80 countries and regions.
- Professional guidance on import documents.
- CO, FORM E, FORM P, pre-implantation inspection
construction sand rock transport truck shipping：
- Maximize save your sea freight.
- Professional guidance on your importing documents.
- Safe, fast and timely
Front lifting dump truck bulk order case:
- Fast shipping to all parts of the world.
- The truck color and logo can be customized.
