Sinotruk Howo 8 ton forward dump truck Description:
- Sinotruk Howo 8 ton forward dump truck also called dump truck, dump tipper, side-turn tipper, dump truck tipping, dumper, tip truck, tipper lorry.
- is a truck used for transporting loose material, such as sand, gravel, coal, dirt, etc.
- ISUZU dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front.
- Or hinged at side with hydraulic pistons to lift the side.
Advantage:
- Sinotruk HOWO chassis, perfect performance
- Sino engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Pay loading from 2ton to 100 tons.
- Easy operation and easy maintenance.
- Virious types of tipper body are available.
- High strength box body
- Excellent Chinese brand hydraulic piston
- Strong, durable, perfect performance
Specification:
| Sinotruk Howo 8 ton forward dump truck for sale swaziland | |
| Chassis Model | ZZ3168E3415C143 (Left/ Right Hand Driving Type Optional) |
| Engine | Model: YC4D130-33, Euro III, 130HP 4-cylinder in-line with water cooling, turbo-charging and intercooling |
| Clutch | Single-plate dry diaphragm spring clutch, diameter 430mm,hydraulically operating with air assistance |
| Gearbox | manual operation, 8JS85F, 8forward and 1 reverse, with Power Take-Off (PTO) |
| Front Axles | 3200kg with drum brake system |
| Rear Axles | 2X10000kg, double stage reduction (central+ hub), cast axle housing, |
| Suspension | Front suspension: 10 pcs leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer |
| Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer | |
| Steering System | power steering, hydraulic steering with power assistance |
| Braking System | Front drum rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake (optional): engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms |
| Tires | 9.00R20, with one spare tyre |
| Fuel Tank Volume (L) | 120 |
| Dead Weight | 600 |
| Gross Vehicle Weight (kg) | 16000 |
| Rated Loading Weight (kg) | 10000 |
| Overall Dimension (LxWxH) (mm) |
6545x2450x3200 |
| Wheelbase (mm) | 3360+1350 |
| Cargo Body Size (LxWxH) (mm) | 3850*2100*800mm |
| Cargo Body Volume (m3) | 7 |
| Remark (Engine Power Option) | 130HP |
Dumper truck Structure:
Tipper truck parts tools and instructions:
Factory Advantage:
- 19 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Documents:
- Serving more than 80 countries and regions.
- Professional guidance on import documents.
- CO, FORM E, FORM P, pre-implantation inspection
construction sand rock transport truck shipping：
- Maximize save your sea freight.
- Professional guidance on your importing documents.
- Safe, fast and timely
Front lifting dump truck bulk order case:
- Fast shipping to all parts of the world.
- The truck color and logo can be customized.
